檢閱您的 Appium 伺服器日誌

注意：此範例使用命令列工具curl從 Device Farm 提取日誌。

在工作階段期間或之後，您可以使用 Device Farm 的 ListArtifacts API 下載 Appium 伺服器日誌。

$ aws devicefarm list-artifacts \
  --type FILE \
  --arn arn:aws:devicefarm:us-west-2:111122223333:session:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000

這會在工作階段期間顯示如下的輸出：

{
    "artifacts": [
        {
            "arn": "arn:aws:devicefarm:us-west-2:111122223333:artifact:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000",
            "name": "AppiumServerLogOutput",
            "type": "APPIUM_SERVER_LOG_OUTPUT",
            "extension": "",
            "url": "https://prod-us-west-2-results.s3.dualstack.us-west-2.amazonaws.com/111122223333/12345678..."
        }
    ]
}

工作階段完成後，還有以下項目：

{
    "artifacts": [
        {
            "arn": "arn:aws:devicefarm:us-west-2:111122223333:artifact:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000",
            "name": "Appium Server Output",
            "type": "APPIUM_SERVER_OUTPUT",
            "extension": "log",
            "url": "https://prod-us-west-2-results.s3.dualstack.us-west-2.amazonaws.com/111122223333/12345678..."
        }
    ]
}

$ curl "https://prod-us-west-2-results.s3.dualstack.us-west-2.amazonaws.com/111122223333/12345678..."

這會顯示如下所示的輸出：

info Appium Welcome to Appium v2.5.4
info Appium Non-default server args:
info Appium { address: '127.0.0.1',
info Appium   allowInsecure:
info Appium    [ 'execute_driver_script',
info Appium      'session_discovery',
info Appium      'perf_record',
info Appium      'adb_shell',
info Appium      'chromedriver_autodownload',
info Appium      'get_server_logs' ],
info Appium   keepAliveTimeout: 0,
info Appium   logNoColors: true,
info Appium   logTimestamp: true,
info Appium   longStacktrace: true,
info Appium   sessionOverride: true,
info Appium   strictCaps: true,
info Appium   useDrivers: [ 'uiautomator' ] }

注意：此範例使用第三方requests套件來下載日誌，以及適用於 Python 的 AWS SDKboto3。

在工作階段期間或之後，您可以使用 Device Farm 的 ListArtifacts API 擷取 Appium 伺服器日誌 URL，然後將其下載。

import pathlib
import requests
import boto3

def download_appium_log():
    session_arn = "arn:aws:devicefarm:us-west-2:111122223333:session:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000"
    client = boto3.client("devicefarm", region_name="us-west-2")

    # 1) List artifacts for the session (FILE artifacts), handling pagination
    artifacts = []
    token = None
    while True:
        kwargs = {"arn": session_arn, "type": "FILE"}
        if token:
            kwargs["nextToken"] = token
        resp = client.list_artifacts(**kwargs)
        artifacts.extend(resp.get("artifacts", []))
        token = resp.get("nextToken")
        if not token:
            break

    if not artifacts:
        raise RuntimeError("No artifacts found in this session")

    # Filter strictly to Appium server logs
    allowed = {"APPIUM_SERVER_OUTPUT", "APPIUM_SERVER_LOG_OUTPUT"}
    filtered = [a for a in artifacts if a.get("type") in allowed]
    if not filtered:
        raise RuntimeError("No Appium server log artifacts found (expected APPIUM_SERVER_OUTPUT or APPIUM_SERVER_LOG_OUTPUT)")

    # Prefer the final 'OUTPUT' log, else the live 'LOG_OUTPUT'
    chosen = (next((a for a in filtered if a.get("type") == "APPIUM_SERVER_OUTPUT"), None)
              or next((a for a in filtered if a.get("type") == "APPIUM_SERVER_LOG_OUTPUT"), None))

    url = chosen["url"]
    ext = chosen.get("extension") or "log"
    out = pathlib.Path(f"./appium_server_log.{ext}")

    # 2) Download the artifact
    with requests.get(url, stream=True) as r:
        r.raise_for_status()
        with open(out, "wb") as fh:
            for chunk in r.iter_content(chunk_size=1024 * 1024):
                if chunk:
                    fh.write(chunk)

    print(f"Saved Appium server log to: {out.resolve()}")

download_appium_log()

這會顯示如下所示的輸出：

info Appium Welcome to Appium v2.5.4
info Appium Non-default server args:
info Appium { address: '127.0.0.1', allowInsecure: [ 'execute_driver_script', ... ], useDrivers: [ 'uiautomator' ] }

注意：此範例使用適用於 Java v2 的 AWS SDK 和 HttpClient 來下載日誌，並與 JDK 第 11 版及更高版本相容。

在工作階段期間或之後，您可以使用 Device Farm 的 ListArtifacts API 擷取 Appium 伺服器日誌 URL，然後將其下載。

import java.io.IOException;
import java.net.URI;
import java.net.http.HttpClient;
import java.net.http.HttpRequest;
import java.net.http.HttpResponse;
import java.nio.file.Path;
import java.time.Duration;
import java.util.ArrayList;
import java.util.Comparator;
import java.util.List;

import software.amazon.awssdk.regions.Region;
import software.amazon.awssdk.services.devicefarm.DeviceFarmClient;
import software.amazon.awssdk.services.devicefarm.model.Artifact;
import software.amazon.awssdk.services.devicefarm.model.ArtifactCategory;
import software.amazon.awssdk.services.devicefarm.model.ListArtifactsRequest;
import software.amazon.awssdk.services.devicefarm.model.ListArtifactsResponse;

public class AppiumLogDownloader {

    public static void main(String[] args) throws Exception {
        String sessionArn = "arn:aws:devicefarm:us-west-2:111122223333:session:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000";

        try (DeviceFarmClient client = DeviceFarmClient.builder()
                .region(Region.US_WEST_2)
                .build()) {

            // 1) List artifacts for the session (FILE artifacts) with pagination
            List<Artifact> all = new ArrayList<>();
            String token = null;
            do {
                ListArtifactsRequest.Builder b = ListArtifactsRequest.builder()
                        .arn(sessionArn)
                        .type(ArtifactCategory.FILE);
                if (token != null) b.nextToken(token);
                ListArtifactsResponse page = client.listArtifacts(b.build());
                all.addAll(page.artifacts());
                token = page.nextToken();
            } while (token != null && !token.isBlank());

            // Filter strictly to Appium logs
            List<Artifact> filtered = all.stream()
                    .filter(a -> {
                        String t = a.typeAsString();
                        return "APPIUM_SERVER_OUTPUT".equals(t) || "APPIUM_SERVER_LOG_OUTPUT".equals(t);
                    })
                    .toList();

            if (filtered.isEmpty()) {
                throw new RuntimeException("No Appium server log artifacts found (expected APPIUM_SERVER_OUTPUT or APPIUM_SERVER_LOG_OUTPUT).");
            }

            // Prefer OUTPUT; else LOG_OUTPUT
            Artifact chosen = filtered.stream()
                    .filter(a -> "APPIUM_SERVER_OUTPUT".equals(a.typeAsString()))
                    .findFirst()
                    .orElseGet(() -> filtered.stream()
                            .filter(a -> "APPIUM_SERVER_LOG_OUTPUT".equals(a.typeAsString()))
                            .findFirst()
                            .get());

            String url = chosen.url();
            String ext = (chosen.extension() == null || chosen.extension().isBlank()) ? "log" : chosen.extension();
            Path out = Path.of("appium_server_log." + ext);

            // 2) Download the artifact with HttpClient
            HttpClient http = HttpClient.newBuilder()
                    .connectTimeout(Duration.ofSeconds(10))
                    .build();

            HttpRequest get = HttpRequest.newBuilder(URI.create(url))
                    .timeout(Duration.ofMinutes(5))
                    .GET()
                    .build();

            HttpResponse<Path> resp = http.send(get, HttpResponse.BodyHandlers.ofFile(out));
            if (resp.statusCode() / 100 != 2) {
                throw new IOException("Failed to download log, HTTP " + resp.statusCode());
            }
            System.out.println("Saved Appium server log to: " + out.toAbsolutePath());
        }
    }
}

這會顯示如下所示的輸出：

info Appium Welcome to Appium v2.5.4
info Appium Non-default server args:
info Appium { address: '127.0.0.1', ..., useDrivers: [ 'uiautomator' ] }

注意：此範例使用適用於 JavaScript 的 AWS SDK (v3) 和 Node 18+ fetch來下載日誌。

在工作階段期間或之後，您可以使用 Device Farm 的 ListArtifacts API 來擷取 Appium 伺服器日誌 URL，然後將其下載。

import { DeviceFarmClient, ListArtifactsCommand } from "@aws-sdk/client-device-farm";
import { createWriteStream } from "fs";
import { pipeline } from "stream";
import { promisify } from "util";

const pipe = promisify(pipeline);
const client = new DeviceFarmClient({ region: "us-west-2" });

const sessionArn = "arn:aws:devicefarm:us-west-2:111122223333:session:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000";

// 1) List artifacts for the session (FILE artifacts), handling pagination
const artifacts = [];
let nextToken;
do {
  const page = await client.send(new ListArtifactsCommand({
    arn: sessionArn,
    type: "FILE",
    nextToken
  }));
  artifacts.push(...(page.artifacts ?? []));
  nextToken = page.nextToken;
} while (nextToken);

if (!artifacts.length) throw new Error("No artifacts found");

// Strict filter to Appium logs
const filtered = (artifacts ?? []).filter(a =>
  a.type === "APPIUM_SERVER_OUTPUT" || a.type === "APPIUM_SERVER_LOG_OUTPUT"
);
if (!filtered.length) {
  throw new Error("No Appium server log artifacts found (expected APPIUM_SERVER_OUTPUT or APPIUM_SERVER_LOG_OUTPUT).");
}

// Prefer OUTPUT; else LOG_OUTPUT
const chosen =
  filtered.find(a => a.type === "APPIUM_SERVER_OUTPUT") ??
  filtered.find(a => a.type === "APPIUM_SERVER_LOG_OUTPUT");

const url = chosen.url;
const ext = chosen.extension || "log";
const outPath = `./appium_server_log.${ext}`;

// 2) Download the artifact
const resp = await fetch(url);
if (!resp.ok) {
  throw new Error(`Failed to download log: ${resp.status} ${await resp.text().catch(()=>"")}`);
}
await pipe(resp.body, createWriteStream(outPath));
console.log("Saved Appium server log to:", outPath);

這會顯示如下所示的輸出：

info Appium Welcome to Appium v2.5.4
info Appium Non-default server args:
info Appium { address: '127.0.0.1', allowInsecure: [ 'execute_driver_script', ... ], useDrivers: [ 'uiautomator' ] }

注意：此範例使用適用於 .NET 的 AWS SDK 和 HttpClient下載日誌。

在工作階段期間或之後，您可以使用 Device Farm 的 ListArtifacts API 擷取 Appium 伺服器日誌 URL，然後將其下載。

using System;
using System.Collections.Generic;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
using System.Linq;
using Amazon;
using Amazon.DeviceFarm;
using Amazon.DeviceFarm.Model;

class AppiumLogDownloader
{
    static async Task Main()
    {
        var sessionArn = "arn:aws:devicefarm:us-west-2:111122223333:session:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000";

        using var client = new AmazonDeviceFarmClient(RegionEndpoint.USWest2);

        // 1) List artifacts for the session (FILE artifacts), handling pagination
        var all = new List<Artifact>();
        string? token = null;
        do
        {
            var page = await client.ListArtifactsAsync(new ListArtifactsRequest
            {
                Arn = sessionArn,
                Type = ArtifactCategory.FILE,
                NextToken = token
            });
            if (page.Artifacts != null) all.AddRange(page.Artifacts);
            token = page.NextToken;
        } while (!string.IsNullOrEmpty(token));

        if (all.Count == 0)
            throw new Exception("No artifacts found");

        // Strict filter to Appium logs
        var filtered = all.Where(a =>
            a.Type == "APPIUM_SERVER_OUTPUT" || a.Type == "APPIUM_SERVER_LOG_OUTPUT").ToList();

        if (filtered.Count == 0)
            throw new Exception("No Appium server log artifacts found (expected APPIUM_SERVER_OUTPUT or APPIUM_SERVER_LOG_OUTPUT).");

        // Prefer OUTPUT; else LOG_OUTPUT
        var chosen = filtered.FirstOrDefault(a => a.Type == "APPIUM_SERVER_OUTPUT")
                    ?? filtered.First(a => a.Type == "APPIUM_SERVER_LOG_OUTPUT");

        var url = chosen.Url;
        var ext = string.IsNullOrWhiteSpace(chosen.Extension) ? "log" : chosen.Extension;
        var outPath = $"./appium_server_log.{ext}";

        // 2) Download the artifact
        using var http = new HttpClient();
        using var resp = await http.GetAsync(url, HttpCompletionOption.ResponseHeadersRead);
        resp.EnsureSuccessStatusCode();
        await using (var fs = File.Create(outPath))
        {
            await resp.Content.CopyToAsync(fs);
        }
        Console.WriteLine($"Saved Appium server log to: {Path.GetFullPath(outPath)}");
    }
}

這會顯示如下所示的輸出：

info Appium Welcome to Appium v2.5.4
info Appium Non-default server args:
info Appium { address: '127.0.0.1', ..., useDrivers: [ 'uiautomator' ] }

注意：此範例使用適用於 Ruby 的 AWS SDK 和 Net::HTTP下載日誌。

在工作階段期間或之後，您可以使用 Device Farm 的 ListArtifacts API 來擷取 Appium 伺服器日誌 URL，然後將其下載。

require "aws-sdk-devicefarm"
require "net/http"
require "uri"

client = Aws::DeviceFarm::Client.new(region: "us-west-2")
session_arn = "arn:aws:devicefarm:us-west-2:111122223333:session:12345678-1111-2222-333-456789abcdef/12345678-1111-2222-333-456789abcdef/00000"

# 1) List artifacts for the session (FILE artifacts), handling pagination
artifacts = []
token = nil
loop do
  page = client.list_artifacts(arn: session_arn, type: "FILE", next_token: token)
  artifacts.concat(page.artifacts || [])
  token = page.next_token
  break if token.nil? || token.empty?
end

raise "No artifacts found" if artifacts.empty?

# Strict filter to Appium logs
filtered = (artifacts || []).select { |a| ["APPIUM_SERVER_OUTPUT", "APPIUM_SERVER_LOG_OUTPUT"].include?(a.type) }
raise "No Appium server log artifacts found (expected APPIUM_SERVER_OUTPUT or APPIUM_SERVER_LOG_OUTPUT)." if filtered.empty?

# Prefer OUTPUT; else LOG_OUTPUT
chosen = filtered.find { |a| a.type == "APPIUM_SERVER_OUTPUT" } ||
         filtered.find { |a| a.type == "APPIUM_SERVER_LOG_OUTPUT" }

url = chosen.url
ext = (chosen.extension && !chosen.extension.empty?) ? chosen.extension : "log"
out_path = "./appium_server_log.#{ext}"

# 2) Download the artifact
uri = URI.parse(url)
Net::HTTP.start(uri.host, uri.port, use_ssl: (uri.scheme == "https")) do |http|
  req = Net::HTTP::Get.new(uri)
  http.request(req) do |resp|
    raise "Failed GET: #{resp.code} #{resp.body}" unless resp.code.to_i / 100 == 2
    File.open(out_path, "wb") { |f| resp.read_body { |chunk| f.write(chunk) } }
  end
end
puts "Saved Appium server log to: #{File.expand_path(out_path)}"

這會顯示如下所示的輸出：

info Appium Welcome to Appium v2.5.4
info Appium Non-default server args:
info Appium { address: '127.0.0.1', allowInsecure: [ 'execute_driver_script', ... ], useDrivers: [ 'uiautomator' ] }
