配置 RES-ready AMIs

输入您的组件详细信息：

1. 对于 “类型”，选择 “构建”。

2. 对于映像操作系统 (OS)，请选择 Linux 或 Windows。

3. 在 “组件名称” 中，输入一个有意义的名称，例如research-and-engineering-studio-vdi-<operating-system>。

4. 输入组件的版本号，并根据需要添加描述。

   key : value

5. 在定义文档中，输入以下定义文件。如果您遇到任何错误，那么 YAML 文件对空间很敏感，这很可能是导致错误的原因。

   重要

   在定义文件中，如果您的 RES 环境版本不是最新版本，请将下载 URI (- source: 's3://research-engineering-studio-us-east-1/releases/latest/res-installation-scripts.tar.gz'2025.06) latest 中的替换为确切的版本号（例如）。

   Linux

   #  Copyright Amazon.com, Inc. or its affiliates. All Rights Reserved.
   #
   #  Licensed under the Apache License, Version 2.0 (the "License"). You may not use this file except in compliance
   #  with the License. A copy of the License is located at
   #
   #      http://www.apache.org/licenses/LICENSE-2.0
   #
   #  or in the 'license' file accompanying this file. This file is distributed on an 'AS IS' BASIS, WITHOUT WARRANTIES
   #  OR CONDITIONS OF ANY KIND, express or implied. See the License for the specific language governing permissions
   #  and limitations under the License.
   name: research-and-engineering-studio-vdi-linux
   description: An RES EC2 Image Builder component to install required RES software dependencies for Linux VDI.
   schemaVersion: 1.0
   parameters:
     - GPUFamily:
         type: string
         description: GPU family (NONE, NVIDIA, or AMD)
         default: NONE
   phases:
     - name: build
       steps:
         - name: PrepareRESBootstrap
           action: ExecuteBash
           onFailure: Abort
           maxAttempts: 3
           inputs:
             commands:
               - "mkdir -p /root/bootstrap/logs"
               - "mkdir -p /root/bootstrap/latest"
         - name: DownloadRESLinuxInstallPackage
           action: S3Download
           onFailure: Abort
           maxAttempts: 3
           inputs:
             - source: "s3://research-engineering-studio-us-east-1/releases/latest/res-installation-scripts.tar.gz"
               destination: "/root/bootstrap/res-installation-scripts/res-installation-scripts.tar.gz"
         - name: RunInstallScript
           action: ExecuteBash
           onFailure: Abort
           maxAttempts: 3
           inputs:
             commands:
               - "cd /root/bootstrap/res-installation-scripts"
               - "tar -xf res-installation-scripts.tar.gz"
               - "cd scripts/virtual-desktop-host/linux"
               - "/bin/bash install.sh -g {{ GPUFamily }}"
         - name: RunInstallPostRebootScript
           action: ExecuteBash
           onFailure: Abort
           maxAttempts: 3
           inputs:
             commands:
               - "cd /root/bootstrap/res-installation-scripts/scripts/virtual-desktop-host/linux"
               - 'sed -i ''/^export AWS_DEFAULT_PROFILE="bootstrap_profile"$/d'' install_post_reboot.sh'
               - "/bin/bash install_post_reboot.sh -g {{ GPUFamily }}"
         - name: PreventAL2023FromUninstallingCronie
           action: ExecuteBash
           onFailure: Abort
           maxAttempts: 3
           inputs:
             commands:
               - "rm -f /tmp/imagebuilder_service/crontab_installed"

   Windows

   #  Copyright Amazon.com, Inc. or its affiliates. All Rights Reserved.
   #
   #  Licensed under the Apache License, Version 2.0 (the "License"). You may not use this file except in compliance
   #  with the License. A copy of the License is located at
   #
   #      http://www.apache.org/licenses/LICENSE-2.0
   #
   #  or in the 'license' file accompanying this file. This file is distributed on an 'AS IS' BASIS, WITHOUT WARRANTIES
   #  OR CONDITIONS OF ANY KIND, express or implied. See the License for the specific language governing permissions
   #  and limitations under the License.
   name: research-and-engineering-studio-vdi-windows
   description: An RES EC2 Image Builder component to install required RES software dependencies for Windows VDI.
   schemaVersion: 1.0

   phases:
     - name: build
       steps:
          - name: CreateRESBootstrapFolder
            action: CreateFolder
            onFailure: Abort
            maxAttempts: 3
            inputs:
               - path: 'C:\Users\Administrator\RES\Bootstrap'
                 overwrite: true
          - name: DownloadRESWindowsInstallPackage
            action: S3Download
            onFailure: Abort
            maxAttempts: 3
            inputs:
               - source: 's3://research-engineering-studio-us-east-1/releases/latest/res-installation-scripts.tar.gz'
                 destination: '{{ build.CreateRESBootstrapFolder.inputs[0].path }}\res-installation-scripts.tar.gz'
          - name: RunInstallScript
            action: ExecutePowerShell
            onFailure: Abort
            maxAttempts: 3
            inputs:
               commands:
                   - 'cd {{ build.CreateRESBootstrapFolder.inputs[0].path }}'
                   - 'tar -xf res-installation-scripts.tar.gz'
                   - 'Import-Module .\scripts\virtual-desktop-host\windows\Install.ps1'
                   - 'Install-WindowsEC2Instance -PrebakeAMI'

6. 创建任何可选标签，然后选择创建组件。

要配置 Image Builder 基础设施，请执行以下操作：

1. 对于 IAM 角色，请输入您之前在中配置的角色准备一个 IAM 角色以访问 RES 环境。

2. 对于实例类型，请选择内存至少 4 GB 且支持您选择的基本 AMI 架构的类型。参见 Amazon EC2 实例类型。

3. 对于 VPC、子网和安全组，您必须允许互联网访问才能下载软件包。还必须允许访问 RES 环境的 cluster-settings DynamoDB 表和 Amazon S3 集群存储桶。

要运行图像管道，请执行以下操作：

1. 从图像管道中，选择在中创建的管道配置 Image Builder 图像管道。

2. 从 “操作” 中选择 “运行管道”。

1. 按照中的软件堆栈 () AMIs说明注册软件堆栈。

2. 对于 AMI ID，请输入内置输出映像的 AMI ID 运行 Image Builder 图像管道。
