OAuth 2.0 authorization URL session binding

To implement OAuth 2.0 authorization URL session binding

1. Create an application URL – For your user-facing browser application, create and host a new URL that is accessible from the user browser and can accept requests from browser redirects. This page should either redirect to an application page that your user can continue with their agent session OR render some basic web page instructing your users to return their currently active agent session. In later parts of the implementation, this page is used for validation of the current user's active session, so this page should also be able to access and maintain your application user session data.

   As an example, your application may have its users interact with an agent at a primary application page like https://myagentapp.com/assistant. You'll want to expose a new URL like https://myagentapp.com/callback that for now will redirect to the primary application page. The actual code logic in your /callback endpoint will be updated later when following this guide.

2. Update workload identity with application URL – (Can be skipped if testing locally via toolkit) Once you have created and hosted an application URL for AgentCore Identity to redirect to, update your workload identity so that the application URL is registered as an AllowedResourceOauth2ReturnUrl. Make sure that the IAM credentials used have permissions to call CreateWorkloadIdentity or UpdateWorkloadIdentity depending on whether you're creating a new workload identity or updating an existing one.

   Note

   For workload identities created on your behalf by AgentCore Runtime or Gateway, the workload identity name will correspond to the runtime ID or gateway ID that is issued by the services.

   Sample UpdateWorkloadIdentity API call:

   aws bedrock-agentcore-control update-workload-identity --name GoogleCalendarAgent \
   --allowed-resource-oauth2-return-urls https://myagentapp.com/callback

3. Create OAuth 2.0 credential provider in AgentCore Identity – To register the OAuth 2.0 credential provider fully, you need permissions to call CreateOauth2CredentialProvider and UpdateOauth2CredentialProvider. Follow these steps:

   • Call CreateOauth2CredentialProvider with placeholders for client ID and client secret.

   • API response will contain an OAuth callback (redirect) URL like: https://bedrock-agentcore.amazonaws.com/identities/callback/123-456-7890

     Record this value as it's specific for each provider that is created and will be needed later by the OAuth 2.0 resource provider.

   • Go to your resource provider (for example, Google or GitHub) and create an OAuth 2.0 application client. Provide the callback URL issued by the service from the CreateOauth2CredentialProvider call to the resource provider as an allowed OAuth 2.0 callback URL.

   • Once the OAuth 2.0 application client has been created, record the client ID and client secret assigned to your app client as you need to update the OAuth 2.0 Credential Provider with these values.

   • Call UpdateOauth2CredentialProvider and provide the client ID and client secret provided by the resource provider, replacing the placeholder values that were provided when creating the credential provider.

4. Add code handler for calling CompleteResourceTokenAuth – Once you have created your OAuth 2.0 credential provider, add code and the IAM permissions to call the CompleteResourceTokenAuth API in your application URL handler. When calling the CompleteResourceTokenAuth API, your application must present the original inbound identity provider OAuth token or user_id String that was used to generate the workload access token to represent the user and the agent application involved in the OAuth 2.0 authorization flow. This information should be fetched from the active application session on the user's browser (typically through a browser cookie or in browser local storage) and should NOT be pulled from any remote session cache.

   Additionally, each authorization URL that gets generated by AgentCore Identity is uniquely identified with its own session URI. This session URI must also be presented alongside the user identifier to bind the session with the intended user.

   Important

   Prior to your application calling the CompleteResourceTokenAuth API, your application must verify that the current user has an active, valid session with your application. By doing so your application can associate the intended user with the Authorization session. Furthermore, if you have a backend service that your application depends on, you can move the code that calls CompleteResourceTokenAuth API to your backend, and have your application forward the inbound identity provider OAuth token or user_id to your backend.

   Sample application code:

   def _handle_3lo_callback(self, request: Request) -> JSONResponse:
       session_id = request.query_params.get("session_id")

       if not session_id:
           console.print("Missing session_id in OAuth2 3LO callback")
           return JSONResponse(status_code=400, content={"message": "missing session_id query parameter"})

       session_details = validate_session_cookies(request.cookies.get('my-application-cookie'))

       user_id = None
       if oauth2_config:
           user_id = session_details.get(USER_ID)

       if not user_id:
           console.print(f"Missing {USER_ID} in session_details")
           return JSONResponse(status_code=500, content={"message": "Internal Server Error"})

       console.print(f"Handling 3LO callback for workload_user_id={user_id} | session_id={session_id}", soft_wrap=True)

       region = agent_config.aws.region
       if not region:
           console.print("AWS Region not configured")
           return JSONResponse(status_code=500, content={"message": "Internal Server Error"})

       identity_client = IdentityClient(region)
       identity_client.complete_resource_token_auth(
           session_uri=session_id, user_identifier=UserIdIdentifier(user_id=user_id)
       )

       return JSONResponse(status_code=200, content={"message": "OAuth2 3LO flow completed successfully"})

5. Test – Once you have completed the setup, you are ready to test the integration. Start by calling GetResourceOauth2Token and in your browser go to the Authorization URL that is returned. After completing the authorization at the OAuth 2.0 resource provider, you should see the browser redirect back to your application URL and invoke the CompleteResourceTokenAuth API. Once the application returns a valid response, your agent application will be able to retrieve the OAuth 2.0 access tokens that were originally requested for the user. These tokens can be fetched by calling the GetResourceOauth2Token API.
