Get started with AgentCore Gateway

In this quick start guide you'll learn how to set up a gateway and integrate it into your agents using the AgentCore starter toolkit. For more comprehensive guides and examples, see the Amazon Bedrock AgentCore Gateway GitHub repository.

Prerequisites

Before starting, make sure you have the followinsg:

Step 1: Setup and install

Run the following in a terminal to set up the virtual environment in which to install the dependencies.

mkdir agentcore-gateway-quickstart
cd agentcore-gateway-quickstart
python3 -m venv .venv
source .venv/bin/activate  # On Windows: .venv\Scripts\activate


Then, run the following to install the dependencies

pip install boto3
pip install bedrock-agentcore-starter-toolkit
pip install strands-agents

Step 2: Create gateway setup script

Create a new file called setup_gateway.py and insert the following complete code into it:

"""
Setup script to create Gateway with Lambda target and save configuration
Run this first: python setup_gateway.py
"""

from bedrock_agentcore_starter_toolkit.operations.gateway.client import GatewayClient
import json
import logging
import time

def setup_gateway():
    # Configuration
    region = "us-east-1"  # Change to your preferred region

    print("🚀 Setting up AgentCore Gateway...")
    print(f"Region: {region}\n")

    # Initialize client
    client = GatewayClient(region_name=region)
    client.logger.setLevel(logging.INFO)

    # Step 2.1: Create OAuth authorizer
    print("Step 2.1: Creating OAuth authorization server...")
    cognito_response = client.create_oauth_authorizer_with_cognito("TestGateway")
    print("✓ Authorization server created\n")

    # Step 2.2: Create Gateway
    print("Step 2.2: Creating Gateway...")
    gateway = client.create_mcp_gateway(
        # the name of the Gateway - if you don't set one, one will be generated.
        name=None,
        # the role arn that the Gateway will use - if you don't set one, one will be created.
        # NOTE: if you are using your own role make sure it has a trust policy that trusts bedrock-agentcore.amazonaws.com
        role_arn=None,
        # the OAuth authorization server details. If you are providing your own authorization server,
        # then pass an input of the following form: {"customJWTAuthorizer": {"allowedClients": ["<INSERT CLIENT ID>"], "discoveryUrl": "<INSERT DISCOVERY URL>"}}
        authorizer_config=cognito_response["authorizer_config"],
        # enable semantic search
        enable_semantic_search=True,
    )
    print(f"✓ Gateway created: {gateway['gatewayUrl']}\n")

    # If role_arn was not provided, fix IAM permissions
    # NOTE: This is handled internally by the toolkit when no role is provided
    client.fix_iam_permissions(gateway)
    print("⏳ Waiting 30s for IAM propagation...")
    time.sleep(30)
    print("✓ IAM permissions configured\n")

    # Step 2.3: Add Lambda target
    print("Step 2.3: Adding Lambda target...")
    lambda_target = client.create_mcp_gateway_target(
        # the gateway created in the previous step
        gateway=gateway,
        # the name of the Target - if you don't set one, one will be generated.
        name=None,
        # the type of the Target
        target_type="lambda",
        # the target details - set this to define your own lambda if you pre-created one.
        # Otherwise leave this None and one will be created for you.
        target_payload=None,
        # you will see later in the tutorial how to use this to connect to APIs using API keys and OAuth credentials.
        credentials=None,
    )
    print("✓ Lambda target added\n")

    # Step 2.4: Save configuration for agent
    config = {
        "gateway_url": gateway["gatewayUrl"],
        "gateway_id": gateway["gatewayId"],
        "region": region,
        "client_info": cognito_response["client_info"]
    }

    with open("gateway_config.json", "w") as f:
        json.dump(config, f, indent=2)

    print("=" * 60)
    print("✅ Gateway setup complete!")
    print(f"Gateway URL: {gateway['gatewayUrl']}")
    print(f"Gateway ID: {gateway['gatewayId']}")
    print("\nConfiguration saved to: gateway_config.json")
    print("\nNext step: Run 'python run_agent.py' to test your Gateway")
    print("=" * 60)

    return config

if __name__ == "__main__":
    setup_gateway()

Expand the following section for a step-by-step understanding of each component.

from bedrock_agentcore_starter_toolkit.operations.gateway.client import GatewayClient
import json
import logging
import time

def setup_gateway():
    # Configuration
    region = "us-east-1"  # Change to your preferred region

    print("🚀 Setting up AgentCore Gateway...")
    print(f"Region: {region}\n")

    # Initialize client
    client = GatewayClient(region_name=region)
    client.logger.setLevel(logging.INFO)

# Step 2.1: Create OAuth authorizer
    print("Step 2.1: Creating OAuth authorization server...")
    cognito_response = client.create_oauth_authorizer_with_cognito("TestGateway")
    print("✓ Authorization server created\n")

# Step 2.2: Create Gateway
    print("Step 2.2: Creating Gateway...")
    gateway = client.create_mcp_gateway(
        # the name of the Gateway - if you don't set one, one will be generated.
        name=None,
        # the role arn that the Gateway will use - if you don't set one, one will be created.
        # NOTE: if you are using your own role make sure it has a trust policy that trusts bedrock-agentcore.amazonaws.com
        role_arn=None,
        # the OAuth authorization server details. If you are providing your own authorization server,
        # then pass an input of the following form: {"customJWTAuthorizer": {"allowedClients": ["<INSERT CLIENT ID>"], "discoveryUrl": "<INSERT DISCOVERY URL>"}}
        authorizer_config=cognito_response["authorizer_config"],
        # enable semantic search
        enable_semantic_search=True,
    )
    print(f"✓ Gateway created: {gateway['gatewayUrl']}\n")

    # If role_arn was not provided, fix IAM permissions
    # NOTE: This is handled internally by the toolkit when no role is provided
    client.fix_iam_permissions(gateway)
    print("⏳ Waiting 30s for IAM propagation...")
    time.sleep(30)
    print("✓ IAM permissions configured\n")

s# Step 2.3: Add Lambda target
    print("Step 2.3: Adding Lambda target...")
    lambda_target = client.create_mcp_gateway_target(
        # the gateway created in the previous step
        gateway=gateway,
        # the name of the Target - if you don't set one, one will be generated.
        name=None,
        # the type of the Target
        target_type="lambda",
        # the target details - set this to define your own lambda if you pre-created one.
        # Otherwise leave this None and one will be created for you.
        target_payload=None,
        # you will see later in the tutorial how to use this to connect to APIs using API keys and OAuth credentials.
        credentials=None,
    )
    print("✓ Lambda target added\n")

# Step 2.4: Save configuration for agent
    config = {
        "gateway_url": gateway["gatewayUrl"],
        "gateway_id": gateway["gatewayId"],
        "region": region,
        "client_info": cognito_response["client_info"]
    }

    with open("gateway_config.json", "w") as f:
        json.dump(config, f, indent=2)

    print("=" * 60)
    print("✅ Gateway setup complete!")
    print(f"Gateway URL: {gateway['gatewayUrl']}")
    print(f"Gateway ID: {gateway['gatewayId']}")
    print("\nConfiguration saved to: gateway_config.json")
    print("\nNext step: Run 'python run_agent.py' to test your Gateway")
    print("=" * 60)

    return config

if __name__ == "__main__":
    setup_gateway()

Step 3: Run the setup

Execute the setup script to create your gateway and invoke the Lambda target.

python setup_gateway.py

What to expect: The script will take about 2-3 minutes to complete. You'll see progress messages for each step.

Step 4: Use the gateway with an agent

Create a new file called run_agent.py and insert the following code:

"""
Agent script to test the Gateway
Run this after setup: python run_agent.py
"""

from strands import Agent
from strands.models import BedrockModel
from strands.tools.mcp.mcp_client import MCPClient
from mcp.client.streamable_http import streamablehttp_client
from bedrock_agentcore_starter_toolkit.operations.gateway.client import GatewayClient
import json
import sys

def create_streamable_http_transport(mcp_url: str, access_token: str):
    return streamablehttp_client(mcp_url, headers={"Authorization": f"Bearer {access_token}"})

def get_full_tools_list(client):
    """Get all tools with pagination support"""
    more_tools = True
    tools = []
    pagination_token = None
    while more_tools:
        tmp_tools = client.list_tools_sync(pagination_token=pagination_token)
        tools.extend(tmp_tools)
        if tmp_tools.pagination_token is None:
            more_tools = False
        else:
            more_tools = True
            pagination_token = tmp_tools.pagination_token
    return tools

def run_agent():
    # Load configuration
    try:
        with open("gateway_config.json", "r") as f:
            config = json.load(f)
    except FileNotFoundError:
        print("❌ Error: gateway_config.json not found!")
        print("Please run 'python setup_gateway.py' first to create the Gateway.")
        sys.exit(1)

    gateway_url = config["gateway_url"]
    client_info = config["client_info"]

    # Get access token for the agent
    print("Getting access token...")
    client = GatewayClient(region_name=config["region"])
    access_token = client.get_access_token_for_cognito(client_info)
    print("✓ Access token obtained\n")

    # Model configuration - change if needed
    model_id = "anthropic.claude-3-7-sonnet-20250219-v1:0"

    print("🤖 Starting AgentCore Gateway Test Agent")
    print(f"Gateway URL: {gateway_url}")
    print(f"Model: {model_id}")
    print("-" * 60)

    # Setup Bedrock model
    bedrockmodel = BedrockModel(
        inference_profile_id=model_id,
        streaming=True,
    )

    # Setup MCP client
    mcp_client = MCPClient(lambda: create_streamable_http_transport(gateway_url, access_token))

    with mcp_client:
        # List available tools
        tools = get_full_tools_list(mcp_client)
        print(f"\n📋 Available tools: {[tool.tool_name for tool in tools]}")
        print("-" * 60)

        # Create agent
        agent = Agent(model=bedrockmodel, tools=tools)

        # Interactive loop
        print("\n💬 Interactive Agent Ready!")
        print("Try asking: 'What's the weather in Seattle?'")
        print("Type 'exit', 'quit', or 'bye' to end.\n")

        while True:
            user_input = input("You: ")
            if user_input.lower() in ["exit", "quit", "bye"]:
                print("👋 Goodbye!")
                break

            print("\n🤔 Thinking...\n")
            response = agent(user_input)
            print(f"\nAgent: {response.message.get('content', response)}\n")

if __name__ == "__main__":
    run_agent()

Run your agent

Test your gateway by running the agent and interacting with the tools.

python run_agent.py

That's it! The agent will start and you can ask questions like:

What you've built

Through this getting started tutorial, you've created the following resources:

Troubleshooting

The following table shows some possible issues and their solutions:

Quick validation

Run the following commands in a terminal to check that your gateway is working.

# Check your Gateway is working
curl -X POST YOUR_GATEWAY_URL \
  -H "Authorization: Bearer YOUR_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

# Watch live logs
aws logs tail /aws/bedrock-agentcore/gateways/YOUR_GATEWAY_ID --follow

Cleanup

Create a cleanup_gateway.py file and insert the following contents:

from bedrock_agentcore_starter_toolkit.operations.gateway.client import GatewayClient
import json

with open("gateway_config.json", "r") as f:
    config = json.load(f)

client = GatewayClient(region_name=config["region"])
client.cleanup_gateway(config["gateway_id"], config["client_info"])
print("✅ Cleanup complete!")

Run the following in a terminal:

python cleanup_gateway.py

Next steps
