aws-sns-lambda

Stability:Stable
Reference Documentation: https://docs.aws.amazon.com/solutions/latest/constructs/
Language Package

Python Logo Python

aws_solutions_constructs.aws_sns_lambda

Typescript Logo Typescript

@aws-solutions-constructs/aws-sns-lambda

Java Logo Java

software.amazon.awsconstructs.services.snslambda

Overview

This AWS Solutions Construct implements an Amazon SNS connected to an AWS Lambda function.

Here is a minimal deployable pattern definition:

Example
Typescript
import { Construct } from 'constructs';
import { Stack, StackProps } from 'aws-cdk-lib';
import { SnsToLambda, SnsToLambdaProps } from "@aws-solutions-constructs/aws-sns-lambda";
import * as lambda from 'aws-cdk-lib/aws-lambda';

new SnsToLambda(this, 'test-sns-lambda', {
  lambdaFunctionProps: {
    runtime: lambda.Runtime.NODEJS_22_X,
    handler: 'index.handler',
    code: lambda.Code.fromAsset(`lambda`)
  }
});
Python
from aws_solutions_constructs.aws_sns_lambda import SnsToLambda
from aws_cdk import (
    aws_lambda as _lambda,
    Stack
)
from constructs import Construct

SnsToLambda(self, 'test_sns_lambda',
            lambda_function_props=_lambda.FunctionProps(
                code=_lambda.Code.from_asset('lambda'),
                runtime=_lambda.Runtime.PYTHON_3_14,
                handler='index.handler'
            )
            )
Java
import software.constructs.Construct;

import software.amazon.awscdk.Stack;
import software.amazon.awscdk.StackProps;
import software.amazon.awscdk.services.lambda.*;
import software.amazon.awscdk.services.lambda.Runtime;
import software.amazon.awsconstructs.services.snslambda.*;

new SnsToLambda(this, "test-lambda-sqs-stack", new SnsToLambdaProps.Builder()
        .lambdaFunctionProps(new FunctionProps.Builder()
                .runtime(Runtime.NODEJS_22_X)
                .code(Code.fromAsset("lambda"))
                .handler("index.handler")
                .build())
        .build());

Pattern Construct Props

Name Type Description

existingLambdaObj?

lambda.Function

Optional - instance of an existing Lambda Function object, providing both this and lambdaFunctionProps will cause an error.

lambdaFunctionProps?

lambda.FunctionProps

Optional - user provided props to override the default props for the Lambda function. Providing both this and existingLambdaObj causes an error.

existingTopicObj?

sns.Topic

Optional - existing instance of SNS topic object, providing both this and topicProps will cause an error.

topicProps?

sns.TopicProps

Optional - user provided properties to override the default properties for the SNS topic. Providing both this and existingTopicObj causes an error.

enableEncryptionWithCustomerManagedKey?

boolean

If no key is provided, this flag determines whether the SNS Topic is encrypted with a new CMK or an AWS managed key. This flag is ignored if any of the following are defined: topicProps.masterKey, encryptionKey or encryptionKeyProps.

encryptionKey?

kms.Key

An optional, imported encryption key to encrypt the SNS Topic with.

encryptionKeyProps?

kms.KeyProps

Optional user provided properties to override the default properties for the KMS encryption key used to encrypt the SNS Topic with.

Pattern Properties

Name Type Description

lambdaFunction

lambda.Function

Returns an instance of the Lambda function created by the pattern.

snsTopic

sns.Topic

Returns an instance of the SNS topic created by the pattern.

Default settings

Out of the box implementation of the Construct without any override will set the following defaults:

Amazon SNS Topic

  • Configure least privilege access permissions for SNS Topic

  • Enable server-side encryption for SNS Topic using AWS managed KMS Key

  • Enforce encryption of data in transit

AWS Lambda Function

  • Configure limited privilege access IAM role for Lambda function

  • Enable reusing connections with Keep-Alive for NodeJs Lambda function

  • Enable X-Ray Tracing

  • Set Environment Variables

    • AWS_NODEJS_CONNECTION_REUSE_ENABLED (for Node 10.x and higher functions)

Architecture

Diagram showing the SNS topic, Lambda Function, CloudWatch log group and IAM role created by the construct

Github

Go to the Github repo for this pattern to view the code, read/create issues and pull requests and more.
