aws-apigateway-dynamodb

Reference Documentation:

https://docs.aws.amazon.com/solutions/latest/constructs/

Language	Package
Python	`aws_solutions_constructs.aws_apigateway_dynamodb`
Typescript	`@aws-solutions-constructs/aws-apigateway-dynamodb`
Java	`software.amazon.awsconstructs.services.apigatewaydynamodb`

Overview

This AWS Solutions Construct implements an Amazon API Gateway REST API connected to Amazon DynamoDB table.

Here is a minimal deployable pattern definition in:

Example

Pattern Construct Props

Name	Type	Description
dynamoTableProps?	`dynamodb.TableProps`	Optional user provided props to override the default props for the DynamoDB Table. Providing both this and `existingTableInterface` causes an error.
existingTableObj?	`dynamodb.Table`	Existing instance of DynamoDB table object, providing both this and `dynamoTableProps` will cause an error.
apiGatewayProps?	`api.RestApiProps`	Optional - user provided props to override the default props for the API Gateway.
createUsagePlan?	boolean	Whether to create a Usage Plan attached to the API. Must be true if apiGatewayProps.defaultMethodOptions.apiKeyRequired is true. @default - true (to match legacy behavior)
resourceName?	`string`	Optional name of the resource on the API Gateway. Defaults to the table’s partitionKeyName
allowCreateOperation?	`boolean`	Whether to deploy an API Gateway Method for POST HTTP operations on the DynamoDB table (i.e. dynamodb:PutItem).
createRequestTemplate?	`string`	API Gateway Request Template for the create method for the default `application/json` content-type. This property is required if the `allowCreateOperation` property is set to true.
additionalCreateRequestTemplates?	`{ [contentType: string]: string; }`	Optional Create Request Templates for content-types other than `application/json`. Use the `createRequestTemplate` property to set the request template for the `application/json` content-type. This property can only be specified if the `allowCreateOperation` property is set to true.
createIntegrationResponses?	`api.IntegrationResponses[]`	Optional, custom API Gateway Integration Response for the create method. This property can only be specified if the `allowCreateOperation` property is set to true.
createMethodResponses?	`api.MethodResponses[]`	Optional, custom API Gateway Method Responses for the create action. default: [{ statusCode: "200", responseParameters: { "method.response.header.Content-Type": true }},{ statusCode: "500", responseParameters: { "method.response.header.Content-Type": true } } ]
allowReadOperation?	`boolean`	Whether to deploy an API Gateway Method for GET HTTP operations on DynamoDB table (i.e. dynamodb:Query).
readRequestTemplate?	`string`	API Gateway Request Template for the read method for the default `application/json` content-type. The default template only supports a partition key and not partition + sort keys.
additionalReadRequestTemplates?	`{ [contentType: string]: string; }`	Optional Read Request Templates for content-types other than `application/json`. Use the `readRequestTemplate` property to set the request template for the `application/json` content-type.
readIntegrationResponses?	`api.IntegrationResponses[]`	Optional, custom API Gateway Integration Response for the read method.
allowUpdateOperation?	`boolean`	Whether to deploy API Gateway Method for PUT HTTP operations on DynamoDB table (i.e. dynamodb:UpdateItem).
readMethodResponses?	`api.MethodResponses[]`	Optional, custom API Gateway Method Responses for the read action. default: [{ statusCode: "200", responseParameters: { "method.response.header.Content-Type": true }},{ statusCode: "500", responseParameters: { "method.response.header.Content-Type": true } } ]
updateRequestTemplate?	`string`	API Gateway Request Template for the update method. This property is required if the `allowUpdateOperation` property is set to true.
additionalUpdateRequestTemplates?	`{ [contentType: string]: string; }`	Optional Update Request Templates for content-types other than `application/json`. Use the `updateRequestTemplate` property to set the request template for the `application/json` content-type. This property can only be specified if the `allowUpdateOperation` property is set to true.
updateIntegrationResponses?	`api.IntegrationResponses[]`	Optional, custom API Gateway Integration Response for the update method. This property can only be specified if the `allowUpdateOperation` property is set to true.
updateMethodResponses?	`api.MethodResponses[]`	Optional, custom API Gateway Method Responses for the update action. default: [{ statusCode: "200", responseParameters: { "method.response.header.Content-Type": true }},{ statusCode: "500", responseParameters: { "method.response.header.Content-Type": true } } ]
allowDeleteOperation?	`boolean`	Whether to deploy API Gateway Method for DELETE HTTP operations on DynamoDB table (i.e. dynamodb:DeleteItem).
deleteRequestTemplate?	`string`	API Gateway Request Template for the delete method for the default `application/json` content-type.
additionalDeleteRequestTemplates?	`{ [contentType: string]: string; }`	Optional Delete request templates for content-types other than `application/json`. Use the `deleteRequestTemplate` property to set the request template for the `application/json` content-type. This property can only be specified if the `allowDeleteOperation` property is set to true.
deleteIntegrationResponses?	`api.IntegrationResponses[]`	Optional, custom API Gateway Integration Response for the delete method. This property can only be specified if the `allowDeleteOperation` property is set to true.
deleteMethodResponses?	`api.MethodResponses[]`	Optional, custom API Gateway Method Responses for the delete action. default: [{ statusCode: "200", responseParameters: { "method.response.header.Content-Type": true }},{ statusCode: "500", responseParameters: { "method.response.header.Content-Type": true } } ]
logGroupProps?	`logs.LogGroupProps`	User provided props to override the default props for for the CloudWatchLogs LogGroup.

Pattern Properties

Name	Type	Description
apiGateway	`api.RestApi`	Returns an instance of the api.RestApi created by the construct.
apiGatewayRole	`iam.Role`	Returns an instance of the iam.Role created by the construct for API Gateway.
dynamoTable	`dynamodb.Table`	Returns an instance of dynamodb.Table created by the construct.
apiGatewayCloudWatchRole?	`iam.Role`	Returns an instance of the iam.Role created by the construct for API Gateway for CloudWatch access.
apiGatewayLogGroup	`logs.LogGroup`	Returns an instance of the LogGroup created by the construct for API Gateway access logging to CloudWatch.

API Gateway Request/Response Template Properties Overview

This construct allows you to implement four DynamoDB API operations, CREATE/READ/UPDATE/DELETE (corresponding the HTTP POST/GET/PUT/DELETE requests respectively). They are completely independent and each follows the same pattern: * Setting allowCreateOperation to true will implement the application/json content-type with default request and response templates * The request template for application/json requests can be customized using the createRequestTemplate prop values * Additional request templates can be specified using the additionalCreateRequestTemplates prop value. Note - these DO NOT replace the application/json content-type * Customized integration responses can be specified for any content type in the createIntegrationResponses prop value.

Supplying any of these values without setting allowCreateOperation to true will result in an error. This pattern is the same for all four API operations.
