Analizza le dipendenze degli oggetti per le migrazioni parziali del database da Oracle a PostgreSQL

Nome utente, Amazon Web Services

Riepilogo

Questo modello descrive l'importanza di identificare e gestire sistematicamente le dipendenze del sistema durante la migrazione di un database Oracle parziale su Amazon Relational Database Service (Amazon RDS) o Amazon Aurora PostgreSQL. In una migrazione parziale, viene migrato solo un sottoinsieme di oggetti e dati del database originale, mentre il database di origine continua a funzionare e servire applicazioni che dipendono da componenti non migrati

È necessario identificare e analizzare l'ambito della migrazione quando si gestiscono database su larga scala con applicazioni strettamente collegate con dipendenze upstream e downstream. Per iniziare una migrazione parziale, identificate gli oggetti dell'ambito, tra cui tabelle, trigger, viste, stored procedure, funzioni e pacchetti. Il processo di identificazione dell'ambito segue un approccio globale:

Una volta compreso come interagiscono le diverse parti del sistema, è possibile pianificare meglio l'ordine corretto per lo spostamento dei componenti del database e ridurre il rischio di errori di migrazione. La tabella seguente elenca diversi tipi di analisi delle dipendenze.

Per mantenere la coerenza tra i sistemi di origine e di destinazione, stabilisci meccanismi di sincronizzazione dei dati durante il periodo di transizione. È inoltre necessario modificare il codice e le funzioni dell'applicazione per gestire la distribuzione dei dati tra i database Oracle di origine e PostgreSQL di destinazione.

Prerequisiti e limitazioni

Prerequisiti

Versioni del prodotto

Architettura

Stack tecnologico di origine

Stack tecnologico Target

Architettura Target

Il diagramma seguente mostra il processo di migrazione da un database Oracle locale ad Amazon RDS for Oracle, che prevede quanto segue:

Per ulteriori informazioni, consulta Integrazione AWS Database Migration Service con AWS Schema Conversion Tool nella documentazione. AWS

Strumenti

Servizi AWS

Altri servizi

Best practice

Per le best practice relative al provisioning e alla migrazione di un database Oracle, consulta Best practice per la migrazione ad Amazon RDS for Oracle.

Epiche

CREATE TABLE REFERENTIAL_ANALYSIS_BASELINE
(CHILD_OWNER VARCHAR2(50 BYTE),
CHILD_NAME VARCHAR2(100 BYTE),
PARENT_OWNER VARCHAR2(50 BYTE),
PARENT_NAME VARCHAR2(50 BYTE),
REFERENCE_PATH VARCHAR2(1000 BYTE));

CREATE TABLE TABLE_READ_OBJECT_DETAILS
(OWNER VARCHAR2(50 BYTE),
TAB_NAME VARCHAR2(50 BYTE),
READER_OWNER VARCHAR2(50 BYTE),
READER_NAME VARCHAR2(50 BYTE),
READER_TYPE VARCHAR2(50 BYTE));

CREATE TABLE TABLE_WRITE_OBJECT_DETAILS
(TABLE_NAME VARCHAR2(100 BYTE),
WRITEOBJ_OWNER VARCHAR2(100 BYTE),
WRITEOBJ_NAME VARCHAR2(100 BYTE),
WRITEOBJ_TYPE VARCHAR2(100 BYTE),
LINE VARCHAR2(100 BYTE),
TEXT VARCHAR2(4000 BYTE),
OWNER VARCHAR2(50 BYTE));

CREATE TABLE OBJECT_PRIVS_ANALYSIS
(OWNER VARCHAR2(50 BYTE),
OBJECT_NAME VARCHAR2(50 BYTE),
USER_NAME VARCHAR2(50 BYTE),
PRIVS VARCHAR2(50 BYTE));

Risoluzione dei problemi

Risorse correlate

Documentazione AWS

Altra documentazione

Informazioni aggiuntive

Script per DEPENDENT_ANALYSIS_BASELINE

CREATE TABLE DEPENDENT_ANALYSIS_BASELINE
(OWNER VARCHAR2(128 BYTE) NOT NULL ENABLE,
OBJECT_NAME VARCHAR2(128 BYTE) NOT NULL ENABLE,
OBJECT_TYPE VARCHAR2(20 BYTE),
DEPEDNCY_LEVEL NUMBER,
PROJECT_NEED VARCHAR2(20 BYTE),
CATAGORY VARCHAR2(4000 BYTE),
COMMENTS VARCHAR2(4000 BYTE),
CATAGORY1 CLOB,
COMMENTS1 CLOB,
CUSTOMER_COMMENTS VARCHAR2(1000 BYTE),
BACKFILL_TO_GUS VARCHAR2(1000 BYTE),
BACKFILL_NEAR_REAL_TIME_OR_BATCH VARCHAR2(1000 BYTE),
PK_EXISTS VARCHAR2(3 BYTE),
UI_EXISTS VARCHAR2(3 BYTE),
LOB_EXISTS VARCHAR2(3 BYTE),
MASTER_LINK VARCHAR2(100 BYTE),
CONSTRAINT PK_DEPENDENT_ANALYSIS_BASELINE PRIMARY KEY (OWNER,OBJECT_NAME,OBJECT_TYPE));

Procedura per SP_WRITER_OBJECTS_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_WRITER_OBJECTS_ANALYSIS IS
BEGIN
  EXECUTE IMMEDIATE 'TRUNCATE TABLE TABLE_WRITE_OBJECT_DETAILS';
  FOR I IN (SELECT OWNER, OBJECT_NAME FROM DEPENDENT_ANALYSIS_BASELINE WHERE OBJECT_TYPE = 'TABLE')
  LOOP
    INSERT INTO TABLE_WRITE_OBJECT_DETAILS(OWNER, TABLE_NAME, WRITEOBJ_OWNER, WRITEOBJ_NAME, WRITEOBJ_TYPE, LINE, TEXT)
    SELECT DISTINCT I.OWNER, I.OBJECT_NAME, OWNER WRITEOBJ_OWNER, NAME, TYPE, LINE, TRIM(TEXT)
    FROM DBA_SOURCE
    WHERE UPPER(TEXT) LIKE '%' || I.OBJECT_NAME || '%'
      AND (UPPER(TEXT) LIKE '%INSERT%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%UPDATE%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%DELETE%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%UPSERT%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%MERGE%' || I.OBJECT_NAME || '%')
      AND UPPER(TEXT) NOT LIKE '%PROCEDURE%'
      AND UPPER(TEXT) NOT LIKE 'PROCEDURE%'
      AND UPPER(TEXT) NOT LIKE '%FUNCTION%'
      AND UPPER(TEXT) NOT LIKE 'FUNCTION%'
      AND UPPER(TEXT) NOT LIKE '%TRIGGER%'
      AND UPPER(TEXT) NOT LIKE 'TRIGGER%'
      AND UPPER(TRIM(TEXT)) NOT LIKE '%AFTER UPDATE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'BEFORE UPDATE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'BEFORE INSERT%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'AFTER INSERT%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'BEFORE DELETE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'AFTER DELETE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE '%GGLOGADM.GG_LOG_ERROR%'
      AND (TRIM(TEXT) NOT LIKE '/*%' AND TRIM(TEXT) NOT LIKE '--%' )
      AND (OWNER, NAME, TYPE) IN (SELECT OWNER, NAME, TYPE FROM DBA_DEPENDENCIES WHERE REFERENCED_NAME = I.OBJECT_NAME);
  END LOOP;
END;

Script per SP_READER_OBJECTS_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_READER_OBJECTS_ANALYSIS IS
BEGIN
  EXECUTE IMMEDIATE 'TRUNCATE TABLE TABLE_READ_OBJECT_DETAILS';
  FOR I IN (SELECT OWNER, OBJECT_NAME FROM DEPENDENT_ANALYSIS_BASELINE WHERE OBJECT_TYPE = 'TABLE')
  LOOP
    INSERT INTO TABLE_READ_OBJECT_DETAILS
    SELECT DISTINCT i.owner, i.object_name, owner, name, type
    FROM dba_dependencies
    WHERE referenced_name = I.OBJECT_NAME
    AND referenced_type = 'TABLE'
    AND type NOT IN ('SYNONYM', 'MATERIALIZED VIEW', 'VIEW')
    AND (owner, name, type) NOT IN (
      SELECT DISTINCT owner, trigger_name, 'TRIGGER'
      FROM dba_triggers
      WHERE table_name = I.OBJECT_NAME
      AND table_owner = i.owner
      UNION ALL
      SELECT DISTINCT owner, name, type
      FROM dba_source
      WHERE upper(text) LIKE '%' || I.OBJECT_NAME || '%'
      AND (upper(text) LIKE '%INSERT %' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%UPDATE% ' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%DELETE %' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%UPSERT %' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%MERGE %' || I.OBJECT_NAME || '%')
      AND upper(text) NOT LIKE '%PROCEDURE %'
      AND upper(text) NOT LIKE 'PROCEDURE %'
      AND upper(text) NOT LIKE '%FUNCTION %'
      AND upper(text) NOT LIKE 'FUNCTION %'
      AND upper(text) NOT LIKE '%TRIGGER %'
      AND upper(text) NOT LIKE 'TRIGGER %'
      AND upper(trim(text)) NOT LIKE 'BEFORE INSERT %'
      AND upper(trim(text)) NOT LIKE 'BEFORE UPDATE %'
      AND upper(trim(text)) NOT LIKE 'BEFORE DELETE %'
      AND upper(trim(text)) NOT LIKE 'AFTER INSERT %'
      AND upper(trim(text)) NOT LIKE 'AFTER UPDATE %'
      AND upper(trim(text)) NOT LIKE 'AFTER DELETE %'
      AND (trim(text) NOT LIKE '/*%' AND trim(text) NOT LIKE '--%'));
  END LOOP;
END;

Script per SP_OBJECT_REFERENTIAL_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_OBJECT_REFERENTIAL_ANALYSIS IS
BEGIN
  EXECUTE IMMEDIATE 'TRUNCATE TABLE REFERENTIAL_ANALYSIS_BASELINE';
  INSERT INTO REFERENTIAL_ANALYSIS_BASELINE
  WITH rel AS (
    SELECT DISTINCT c.owner, c.table_name, c.r_owner r_owner,
      (SELECT table_name FROM dba_constraints
       WHERE constraint_name = c.r_constraint_name
       AND owner = c.r_owner) r_table_name
    FROM dba_constraints c
    WHERE constraint_type = 'R'
    AND c.owner NOT IN (SELECT username FROM dba_users WHERE oracle_maintained = 'Y')
    AND c.r_owner NOT IN (SELECT username FROM dba_users WHERE oracle_maintained = 'Y')),
  tab_list AS (
    SELECT OWNER, object_name
    FROM DEPENDENT_ANALYSIS_BASELINE
    WHERE UPPER(OBJECT_TYPE) = 'TABLE')
  SELECT DISTINCT owner child_owner, table_name child, r_owner parent_owner,
    r_table_name parent, SYS_CONNECT_BY_PATH(r_table_name, ' -> ') || ' -> ' || table_name PATH
  FROM rel
  START WITH (r_owner, r_table_name) IN (SELECT * FROM tab_list)
  CONNECT BY NOCYCLE (r_owner, r_table_name) = ((PRIOR owner, PRIOR table_name))
  UNION
  SELECT DISTINCT owner child_owner, table_name child, r_owner parent_owner,
    r_table_name parent, SYS_CONNECT_BY_PATH(table_name, ' -> ') || ' -> ' || r_table_name PATH
  FROM rel
  START WITH (owner, table_name) IN (SELECT * FROM tab_list)
  CONNECT BY NOCYCLE (owner, table_name) = ((PRIOR r_owner, PRIOR r_table_name));
END;

Script per SP_OBJECT_PRIVS_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_OBJECT_PRIVS_ANALYSIS IS
  V_SQL VARCHAR2(4000);
  V_CNT NUMBER;
BEGIN
  V_SQL := 'TRUNCATE TABLE OBJECT_PRIVS_ANALYSIS';
  EXECUTE IMMEDIATE V_SQL;
  FOR I IN (SELECT OWNER, OBJECT_NAME FROM DEPENDENT_ANALYSIS_BASELINE WHERE OBJECT_TYPE = 'TABLE')
  LOOP
    INSERT INTO OBJECT_PRIVS_ANALYSIS(OWNER, OBJECT_NAME, USER_NAME, PRIVS)
    WITH obj_to_role AS (
      SELECT DISTINCT GRANTEE role_name,
        DECODE(privilege, 'SELECT', 'READ', 'REFERENCE', 'READ', 'INSERT', 'WRITE',
               'UPDATE', 'WRITE', 'DELETE', 'WRITE', privilege) privs
      FROM DBA_TAB_PRIVS t, DBA_ROLES r
      WHERE OWNER = I.OWNER
      AND TYPE = 'TABLE'
      AND TABLE_NAME = I.OBJECT_NAME
      AND t.GRANTEE = r.ROLE
      AND r.ROLE IN (SELECT ROLE FROM DBA_ROLES WHERE ORACLE_MAINTAINED = 'N')
    )
    SELECT I.OWNER, I.OBJECT_NAME, grantee, privs
    FROM (
      -- Recursively Role to User mapping with privilege
      SELECT DISTINCT grantee, privs
      FROM (SELECT rp.granted_role, rp.grantee, privs,
        (SELECT DECODE(COUNT(*), 0, 'ROLE', 'USER')
         FROM (SELECT 'User' FROM DBA_users WHERE username = rp.GRANTEE)) grantee_type
        FROM DBA_role_privs rp, obj_to_role r
        WHERE rp.granted_role = r.role_name
        AND grantee IN ((SELECT USERNAME FROM DBA_USERS WHERE ORACLE_MAINTAINED = 'N')
                       UNION (SELECT ROLE FROM DBA_ROLES WHERE ORACLE_MAINTAINED = 'N'))
        AND granted_role IN (SELECT ROLE FROM DBA_ROLES WHERE ORACLE_MAINTAINED = 'N')
        START WITH granted_role IN (SELECT DISTINCT role_name FROM obj_to_role)
        CONNECT BY granted_role = PRIOR grantee)
      WHERE grantee_type = 'USER'
    )
    UNION
    (
      -- Direct Object grants to User
      SELECT I.OWNER, I.OBJECT_NAME, GRANTEE,
        DECODE(privilege, 'SELECT', 'READ', 'REFERENCE', 'READ', 'INSERT', 'WRITE',
               'UPDATE', 'WRITE', 'DELETE', 'WRITE', privilege) privs
      FROM DBA_TAB_PRIVS, DBA_USERS
      WHERE GRANTEE = USERNAME
      AND OWNER = I.OWNER
      AND TYPE = 'TABLE'
      AND TABLE_NAME = I.OBJECT_NAME
    )
    ORDER BY 2 DESC;
  END LOOP;
END;

Procedura per SP_OBJECT_DEPENDENCY_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_OBJECT_DEPENDENCY_ANALYSIS (v_level NUMBER) IS
  TYPE typ IS RECORD (
    schema VARCHAR2(100),
    obj_type VARCHAR2(100),
    obj_name VARCHAR2(100),
    path VARCHAR2(5000)
  );
  TYPE array IS TABLE OF typ;
  l_data array;
  c SYS_REFCURSOR;
  l_errors NUMBER;
  l_errno NUMBER;
  l_msg VARCHAR2(4000);
  l_idx NUMBER;
  l_level NUMBER;
BEGIN
  l_level := v_level + 1;
  OPEN c FOR
    WITH obj_list AS (
      SELECT owner schema_name, object_type, object_name
      FROM DEPENDENT_ANALYSIS_BASELINE
      WHERE depedncy_level = v_level
    ),
    fw_dep_objects AS (
      SELECT level lvl, owner, name, type, referenced_owner, referenced_name,
        referenced_type, SYS_CONNECT_BY_PATH(name, ' -> ') || ' -> ' || referenced_name PATH
      FROM dba_dependencies
      START WITH (owner, CASE WHEN type = 'PACKAGE BODY' THEN 'PACKAGE' ELSE type END, name)
        IN (SELECT schema_name, object_type, object_name FROM obj_list)
      CONNECT BY NOCYCLE (owner, type, name) =
        ((PRIOR referenced_owner, PRIOR referenced_type, PRIOR referenced_name))
    ),
    bw_dep_objects AS (
      SELECT level lvl, owner, name, type, referenced_owner, referenced_name,
        referenced_type, SYS_CONNECT_BY_PATH(name, ' <- ') || ' <- ' || referenced_name PATH
      FROM dba_dependencies
      START WITH (referenced_owner, CASE WHEN referenced_type = 'PACKAGE BODY' THEN 'PACKAGE'
        ELSE referenced_type END, referenced_name) IN (SELECT schema_name, object_type, object_name FROM obj_list)
      CONNECT BY NOCYCLE (referenced_owner, referenced_type, referenced_name) =
        ((PRIOR owner, PRIOR type, PRIOR name))
    )
    SELECT * FROM (
      (SELECT DISTINCT referenced_owner schema, referenced_type obj_type,
        referenced_name obj_name, path FROM fw_dep_objects)
      UNION
      (SELECT DISTINCT owner schema, type obj_type, name obj_name, path
       FROM bw_dep_objects)
    )
    WHERE schema IN (SELECT username FROM all_users WHERE oracle_maintained = 'N')
    ORDER BY obj_type;

  LOOP
    FETCH c BULK COLLECT INTO l_data LIMIT 100;
    BEGIN
      FORALL i IN 1..l_data.count SAVE EXCEPTIONS
        INSERT INTO DEPENDENT_ANALYSIS_BASELINE (
          owner, object_name, object_type, catagory, depedncy_level, project_need, comments
        )
        VALUES (
          l_data(i).schema,
          l_data(i).obj_name,
          CASE WHEN l_data(i).obj_type = 'PACKAGE BODY' THEN 'PACKAGE' ELSE l_data(i).obj_type END,
          'level ' || l_level || ' dependency',
          l_level,
          '',
          'from dependency proc' || l_data(i).path
        );
    EXCEPTION
      WHEN OTHERS THEN
        l_errors := sql%bulk_exceptions.count;
        FOR i IN 1..l_errors LOOP
          l_errno := sql%bulk_exceptions(i).error_code;
          l_msg := SQLERRM(-l_errno);
          l_idx := sql%bulk_exceptions(i).error_index;
          UPDATE DEPENDENT_ANALYSIS_BASELINE
          SET catagory1 = catagory1 || ', found in level' || l_level || ' dependent of ' || l_data(l_idx).path,
              comments1 = comments1 || ', from dependency proc exception ' || l_data(i).path
          WHERE owner = l_data(l_idx).schema
          AND object_name = l_data(l_idx).obj_name
          AND object_type = l_data(l_idx).obj_type;
        END LOOP;
    END;
    EXIT WHEN c%NOTFOUND;
  END LOOP;
  CLOSE c;
END;
