Analyser les dépendances des objets pour les migrations partielles de bases de données d'Oracle vers PostgreSQL

anuradha chintha, Amazon Web Services

Récapitulatif

Ce modèle décrit l'importance d'identifier et de gérer systématiquement les dépendances du système lors de la migration d'une base de données Oracle partielle vers Amazon Relational Database Service (Amazon RDS) ou Amazon Aurora PostgreSQL. Lors d'une migration partielle, seul un sous-ensemble d'objets de base de données et de données de la base de données d'origine est migré, tandis que la base de données source continue de fonctionner et de servir les applications qui dépendent de composants non migrés.

Vous devez identifier et analyser l'étendue de la migration lorsque vous manipulez des bases de données à grande échelle comportant des applications étroitement couplées avec des dépendances en amont et en aval. Pour commencer une migration partielle, identifiez les objets du scope, notamment les tables, les déclencheurs, les vues, les procédures stockées, les fonctions et les packages. Le processus d'identification du périmètre suit une approche globale :

Lorsque vous comprenez comment les différentes parties de votre système interagissent, vous pouvez mieux planifier l'ordre correct pour déplacer les composants de base de données et réduire le risque d'échec de la migration. Le tableau suivant répertorie les différents types d'analyse de dépendance.

Pour maintenir la cohérence entre les systèmes source et cible, établissez des mécanismes de synchronisation des données pendant la période de transition. Vous devez également modifier le code et les fonctions de l'application pour gérer la distribution des données dans les bases de données Oracle source et PostgreSQL cible.

Conditions préalables et limitations

Prérequis

Versions du produit

Architecture

Pile technologique source

Pile technologique cible

Architecture cible

Le schéma suivant montre le processus de migration d'une base de données Oracle sur site vers Amazon RDS for Oracle, qui implique les étapes suivantes :

Pour plus d'informations, consultez la section Intégration AWS Database Migration Service avec AWS Schema Conversion Tool dans la AWS documentation.

Outils

Services AWS

Autres services

Bonnes pratiques

Pour connaître les meilleures pratiques relatives au provisionnement et à la migration d'une base de données Oracle, consultez la section Meilleures pratiques pour la migration vers Amazon RDS for Oracle.

Épopées

CREATE TABLE REFERENTIAL_ANALYSIS_BASELINE
(CHILD_OWNER VARCHAR2(50 BYTE),
CHILD_NAME VARCHAR2(100 BYTE),
PARENT_OWNER VARCHAR2(50 BYTE),
PARENT_NAME VARCHAR2(50 BYTE),
REFERENCE_PATH VARCHAR2(1000 BYTE));

CREATE TABLE TABLE_READ_OBJECT_DETAILS
(OWNER VARCHAR2(50 BYTE),
TAB_NAME VARCHAR2(50 BYTE),
READER_OWNER VARCHAR2(50 BYTE),
READER_NAME VARCHAR2(50 BYTE),
READER_TYPE VARCHAR2(50 BYTE));

CREATE TABLE TABLE_WRITE_OBJECT_DETAILS
(TABLE_NAME VARCHAR2(100 BYTE),
WRITEOBJ_OWNER VARCHAR2(100 BYTE),
WRITEOBJ_NAME VARCHAR2(100 BYTE),
WRITEOBJ_TYPE VARCHAR2(100 BYTE),
LINE VARCHAR2(100 BYTE),
TEXT VARCHAR2(4000 BYTE),
OWNER VARCHAR2(50 BYTE));

CREATE TABLE OBJECT_PRIVS_ANALYSIS
(OWNER VARCHAR2(50 BYTE),
OBJECT_NAME VARCHAR2(50 BYTE),
USER_NAME VARCHAR2(50 BYTE),
PRIVS VARCHAR2(50 BYTE));

Dépannage

Ressources connexes

Documentation AWS

Autre documentation

Informations supplémentaires

Script pour DEPENDENT_ANALYSIS_BASELINE

CREATE TABLE DEPENDENT_ANALYSIS_BASELINE
(OWNER VARCHAR2(128 BYTE) NOT NULL ENABLE,
OBJECT_NAME VARCHAR2(128 BYTE) NOT NULL ENABLE,
OBJECT_TYPE VARCHAR2(20 BYTE),
DEPEDNCY_LEVEL NUMBER,
PROJECT_NEED VARCHAR2(20 BYTE),
CATAGORY VARCHAR2(4000 BYTE),
COMMENTS VARCHAR2(4000 BYTE),
CATAGORY1 CLOB,
COMMENTS1 CLOB,
CUSTOMER_COMMENTS VARCHAR2(1000 BYTE),
BACKFILL_TO_GUS VARCHAR2(1000 BYTE),
BACKFILL_NEAR_REAL_TIME_OR_BATCH VARCHAR2(1000 BYTE),
PK_EXISTS VARCHAR2(3 BYTE),
UI_EXISTS VARCHAR2(3 BYTE),
LOB_EXISTS VARCHAR2(3 BYTE),
MASTER_LINK VARCHAR2(100 BYTE),
CONSTRAINT PK_DEPENDENT_ANALYSIS_BASELINE PRIMARY KEY (OWNER,OBJECT_NAME,OBJECT_TYPE));

Procédure pour SP_WRITER_OBJECTS_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_WRITER_OBJECTS_ANALYSIS IS
BEGIN
  EXECUTE IMMEDIATE 'TRUNCATE TABLE TABLE_WRITE_OBJECT_DETAILS';
  FOR I IN (SELECT OWNER, OBJECT_NAME FROM DEPENDENT_ANALYSIS_BASELINE WHERE OBJECT_TYPE = 'TABLE')
  LOOP
    INSERT INTO TABLE_WRITE_OBJECT_DETAILS(OWNER, TABLE_NAME, WRITEOBJ_OWNER, WRITEOBJ_NAME, WRITEOBJ_TYPE, LINE, TEXT)
    SELECT DISTINCT I.OWNER, I.OBJECT_NAME, OWNER WRITEOBJ_OWNER, NAME, TYPE, LINE, TRIM(TEXT)
    FROM DBA_SOURCE
    WHERE UPPER(TEXT) LIKE '%' || I.OBJECT_NAME || '%'
      AND (UPPER(TEXT) LIKE '%INSERT%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%UPDATE%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%DELETE%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%UPSERT%' || I.OBJECT_NAME || '%'
        OR UPPER(TEXT) LIKE '%MERGE%' || I.OBJECT_NAME || '%')
      AND UPPER(TEXT) NOT LIKE '%PROCEDURE%'
      AND UPPER(TEXT) NOT LIKE 'PROCEDURE%'
      AND UPPER(TEXT) NOT LIKE '%FUNCTION%'
      AND UPPER(TEXT) NOT LIKE 'FUNCTION%'
      AND UPPER(TEXT) NOT LIKE '%TRIGGER%'
      AND UPPER(TEXT) NOT LIKE 'TRIGGER%'
      AND UPPER(TRIM(TEXT)) NOT LIKE '%AFTER UPDATE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'BEFORE UPDATE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'BEFORE INSERT%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'AFTER INSERT%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'BEFORE DELETE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE 'AFTER DELETE%'
      AND UPPER(TRIM(TEXT)) NOT LIKE '%GGLOGADM.GG_LOG_ERROR%'
      AND (TRIM(TEXT) NOT LIKE '/*%' AND TRIM(TEXT) NOT LIKE '--%' )
      AND (OWNER, NAME, TYPE) IN (SELECT OWNER, NAME, TYPE FROM DBA_DEPENDENCIES WHERE REFERENCED_NAME = I.OBJECT_NAME);
  END LOOP;
END;

Script pour SP_READER_OBJECTS_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_READER_OBJECTS_ANALYSIS IS
BEGIN
  EXECUTE IMMEDIATE 'TRUNCATE TABLE TABLE_READ_OBJECT_DETAILS';
  FOR I IN (SELECT OWNER, OBJECT_NAME FROM DEPENDENT_ANALYSIS_BASELINE WHERE OBJECT_TYPE = 'TABLE')
  LOOP
    INSERT INTO TABLE_READ_OBJECT_DETAILS
    SELECT DISTINCT i.owner, i.object_name, owner, name, type
    FROM dba_dependencies
    WHERE referenced_name = I.OBJECT_NAME
    AND referenced_type = 'TABLE'
    AND type NOT IN ('SYNONYM', 'MATERIALIZED VIEW', 'VIEW')
    AND (owner, name, type) NOT IN (
      SELECT DISTINCT owner, trigger_name, 'TRIGGER'
      FROM dba_triggers
      WHERE table_name = I.OBJECT_NAME
      AND table_owner = i.owner
      UNION ALL
      SELECT DISTINCT owner, name, type
      FROM dba_source
      WHERE upper(text) LIKE '%' || I.OBJECT_NAME || '%'
      AND (upper(text) LIKE '%INSERT %' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%UPDATE% ' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%DELETE %' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%UPSERT %' || I.OBJECT_NAME || '%'
        OR upper(text) LIKE '%MERGE %' || I.OBJECT_NAME || '%')
      AND upper(text) NOT LIKE '%PROCEDURE %'
      AND upper(text) NOT LIKE 'PROCEDURE %'
      AND upper(text) NOT LIKE '%FUNCTION %'
      AND upper(text) NOT LIKE 'FUNCTION %'
      AND upper(text) NOT LIKE '%TRIGGER %'
      AND upper(text) NOT LIKE 'TRIGGER %'
      AND upper(trim(text)) NOT LIKE 'BEFORE INSERT %'
      AND upper(trim(text)) NOT LIKE 'BEFORE UPDATE %'
      AND upper(trim(text)) NOT LIKE 'BEFORE DELETE %'
      AND upper(trim(text)) NOT LIKE 'AFTER INSERT %'
      AND upper(trim(text)) NOT LIKE 'AFTER UPDATE %'
      AND upper(trim(text)) NOT LIKE 'AFTER DELETE %'
      AND (trim(text) NOT LIKE '/*%' AND trim(text) NOT LIKE '--%'));
  END LOOP;
END;

Script pour SP_OBJECT_REFERENTIAL_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_OBJECT_REFERENTIAL_ANALYSIS IS
BEGIN
  EXECUTE IMMEDIATE 'TRUNCATE TABLE REFERENTIAL_ANALYSIS_BASELINE';
  INSERT INTO REFERENTIAL_ANALYSIS_BASELINE
  WITH rel AS (
    SELECT DISTINCT c.owner, c.table_name, c.r_owner r_owner,
      (SELECT table_name FROM dba_constraints
       WHERE constraint_name = c.r_constraint_name
       AND owner = c.r_owner) r_table_name
    FROM dba_constraints c
    WHERE constraint_type = 'R'
    AND c.owner NOT IN (SELECT username FROM dba_users WHERE oracle_maintained = 'Y')
    AND c.r_owner NOT IN (SELECT username FROM dba_users WHERE oracle_maintained = 'Y')),
  tab_list AS (
    SELECT OWNER, object_name
    FROM DEPENDENT_ANALYSIS_BASELINE
    WHERE UPPER(OBJECT_TYPE) = 'TABLE')
  SELECT DISTINCT owner child_owner, table_name child, r_owner parent_owner,
    r_table_name parent, SYS_CONNECT_BY_PATH(r_table_name, ' -> ') || ' -> ' || table_name PATH
  FROM rel
  START WITH (r_owner, r_table_name) IN (SELECT * FROM tab_list)
  CONNECT BY NOCYCLE (r_owner, r_table_name) = ((PRIOR owner, PRIOR table_name))
  UNION
  SELECT DISTINCT owner child_owner, table_name child, r_owner parent_owner,
    r_table_name parent, SYS_CONNECT_BY_PATH(table_name, ' -> ') || ' -> ' || r_table_name PATH
  FROM rel
  START WITH (owner, table_name) IN (SELECT * FROM tab_list)
  CONNECT BY NOCYCLE (owner, table_name) = ((PRIOR r_owner, PRIOR r_table_name));
END;

Script pour SP_OBJECT_PRIVS_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_OBJECT_PRIVS_ANALYSIS IS
  V_SQL VARCHAR2(4000);
  V_CNT NUMBER;
BEGIN
  V_SQL := 'TRUNCATE TABLE OBJECT_PRIVS_ANALYSIS';
  EXECUTE IMMEDIATE V_SQL;
  FOR I IN (SELECT OWNER, OBJECT_NAME FROM DEPENDENT_ANALYSIS_BASELINE WHERE OBJECT_TYPE = 'TABLE')
  LOOP
    INSERT INTO OBJECT_PRIVS_ANALYSIS(OWNER, OBJECT_NAME, USER_NAME, PRIVS)
    WITH obj_to_role AS (
      SELECT DISTINCT GRANTEE role_name,
        DECODE(privilege, 'SELECT', 'READ', 'REFERENCE', 'READ', 'INSERT', 'WRITE',
               'UPDATE', 'WRITE', 'DELETE', 'WRITE', privilege) privs
      FROM DBA_TAB_PRIVS t, DBA_ROLES r
      WHERE OWNER = I.OWNER
      AND TYPE = 'TABLE'
      AND TABLE_NAME = I.OBJECT_NAME
      AND t.GRANTEE = r.ROLE
      AND r.ROLE IN (SELECT ROLE FROM DBA_ROLES WHERE ORACLE_MAINTAINED = 'N')
    )
    SELECT I.OWNER, I.OBJECT_NAME, grantee, privs
    FROM (
      -- Recursively Role to User mapping with privilege
      SELECT DISTINCT grantee, privs
      FROM (SELECT rp.granted_role, rp.grantee, privs,
        (SELECT DECODE(COUNT(*), 0, 'ROLE', 'USER')
         FROM (SELECT 'User' FROM DBA_users WHERE username = rp.GRANTEE)) grantee_type
        FROM DBA_role_privs rp, obj_to_role r
        WHERE rp.granted_role = r.role_name
        AND grantee IN ((SELECT USERNAME FROM DBA_USERS WHERE ORACLE_MAINTAINED = 'N')
                       UNION (SELECT ROLE FROM DBA_ROLES WHERE ORACLE_MAINTAINED = 'N'))
        AND granted_role IN (SELECT ROLE FROM DBA_ROLES WHERE ORACLE_MAINTAINED = 'N')
        START WITH granted_role IN (SELECT DISTINCT role_name FROM obj_to_role)
        CONNECT BY granted_role = PRIOR grantee)
      WHERE grantee_type = 'USER'
    )
    UNION
    (
      -- Direct Object grants to User
      SELECT I.OWNER, I.OBJECT_NAME, GRANTEE,
        DECODE(privilege, 'SELECT', 'READ', 'REFERENCE', 'READ', 'INSERT', 'WRITE',
               'UPDATE', 'WRITE', 'DELETE', 'WRITE', privilege) privs
      FROM DBA_TAB_PRIVS, DBA_USERS
      WHERE GRANTEE = USERNAME
      AND OWNER = I.OWNER
      AND TYPE = 'TABLE'
      AND TABLE_NAME = I.OBJECT_NAME
    )
    ORDER BY 2 DESC;
  END LOOP;
END;

Procédure pour SP_OBJECT_DEPENDENCY_ANALYSIS

CREATE OR REPLACE PROCEDURE SP_OBJECT_DEPENDENCY_ANALYSIS (v_level NUMBER) IS
  TYPE typ IS RECORD (
    schema VARCHAR2(100),
    obj_type VARCHAR2(100),
    obj_name VARCHAR2(100),
    path VARCHAR2(5000)
  );
  TYPE array IS TABLE OF typ;
  l_data array;
  c SYS_REFCURSOR;
  l_errors NUMBER;
  l_errno NUMBER;
  l_msg VARCHAR2(4000);
  l_idx NUMBER;
  l_level NUMBER;
BEGIN
  l_level := v_level + 1;
  OPEN c FOR
    WITH obj_list AS (
      SELECT owner schema_name, object_type, object_name
      FROM DEPENDENT_ANALYSIS_BASELINE
      WHERE depedncy_level = v_level
    ),
    fw_dep_objects AS (
      SELECT level lvl, owner, name, type, referenced_owner, referenced_name,
        referenced_type, SYS_CONNECT_BY_PATH(name, ' -> ') || ' -> ' || referenced_name PATH
      FROM dba_dependencies
      START WITH (owner, CASE WHEN type = 'PACKAGE BODY' THEN 'PACKAGE' ELSE type END, name)
        IN (SELECT schema_name, object_type, object_name FROM obj_list)
      CONNECT BY NOCYCLE (owner, type, name) =
        ((PRIOR referenced_owner, PRIOR referenced_type, PRIOR referenced_name))
    ),
    bw_dep_objects AS (
      SELECT level lvl, owner, name, type, referenced_owner, referenced_name,
        referenced_type, SYS_CONNECT_BY_PATH(name, ' <- ') || ' <- ' || referenced_name PATH
      FROM dba_dependencies
      START WITH (referenced_owner, CASE WHEN referenced_type = 'PACKAGE BODY' THEN 'PACKAGE'
        ELSE referenced_type END, referenced_name) IN (SELECT schema_name, object_type, object_name FROM obj_list)
      CONNECT BY NOCYCLE (referenced_owner, referenced_type, referenced_name) =
        ((PRIOR owner, PRIOR type, PRIOR name))
    )
    SELECT * FROM (
      (SELECT DISTINCT referenced_owner schema, referenced_type obj_type,
        referenced_name obj_name, path FROM fw_dep_objects)
      UNION
      (SELECT DISTINCT owner schema, type obj_type, name obj_name, path
       FROM bw_dep_objects)
    )
    WHERE schema IN (SELECT username FROM all_users WHERE oracle_maintained = 'N')
    ORDER BY obj_type;

  LOOP
    FETCH c BULK COLLECT INTO l_data LIMIT 100;
    BEGIN
      FORALL i IN 1..l_data.count SAVE EXCEPTIONS
        INSERT INTO DEPENDENT_ANALYSIS_BASELINE (
          owner, object_name, object_type, catagory, depedncy_level, project_need, comments
        )
        VALUES (
          l_data(i).schema,
          l_data(i).obj_name,
          CASE WHEN l_data(i).obj_type = 'PACKAGE BODY' THEN 'PACKAGE' ELSE l_data(i).obj_type END,
          'level ' || l_level || ' dependency',
          l_level,
          '',
          'from dependency proc' || l_data(i).path
        );
    EXCEPTION
      WHEN OTHERS THEN
        l_errors := sql%bulk_exceptions.count;
        FOR i IN 1..l_errors LOOP
          l_errno := sql%bulk_exceptions(i).error_code;
          l_msg := SQLERRM(-l_errno);
          l_idx := sql%bulk_exceptions(i).error_index;
          UPDATE DEPENDENT_ANALYSIS_BASELINE
          SET catagory1 = catagory1 || ', found in level' || l_level || ' dependent of ' || l_data(l_idx).path,
              comments1 = comments1 || ', from dependency proc exception ' || l_data(i).path
          WHERE owner = l_data(l_idx).schema
          AND object_name = l_data(l_idx).obj_name
          AND object_type = l_data(l_idx).obj_type;
        END LOOP;
    END;
    EXIT WHEN c%NOTFOUND;
  END LOOP;
  CLOSE c;
END;
